Model S presenting door handles are spring-returned to the flush position. A small DC motor drives a gear pawl that protracts the handle on touch, under control of the door module via LIN bus.
Early “V1” paddle/gear designs used cast aluminum that can crack at the retainer shaft, causing jams or a handle that won’t retract. Our improved replacement restores reliable presentation.
A LIN-controlled DC motor drives the gear pawl to present/retract the handle. Microswitches track positions and usage to
coordinate latch and illumination. When the gear hub fails, commanded motion can no longer maintain position.
We stock parts for mail-out repair kits and offer in-shop service. If your handle is stuck out or intermittent, this part addresses the most common root cause.
| Category | Detail |
| Application | Tesla Model S presenting door handle mechanism (all positions) |
| Function | Motor-driven gear pawl to present/retract handle; interfaces with LIN DCM |
| Failure Symptom | Handle stuck out, won’t present, or falls back into cavity; audible grind/click |
| Included | Upgraded gear pawl (assembly repair part). Reuse motor, housing, switches. |
Available as a part-only shipment nationwide or installed at our North Phoenix Service Center.
Ship-in handle repairs also available—contact us for turnaround times.
Reduce shock-loading: avoid repeated rapid taps when the handle is already moving; allow full extend/retract cycles.
Questions or installation guidance? Call 623-433-8500.
